RCMK090700 Carbide Insert, Grade KC5010, AlTiN - Kennametal 1865953

Kennametal

RCMK090700 Carbide Insert, Grade KC5010, AlTiN - Kennametal 1865953

MFR# 1865953ISO/ANSI# RCMK090700Series K-LOCK

$27.68List $33.20 Save 16%
Usually ships in 1-3 business days

Ship times are estimates. We confirm availability on every order and email you right away if anything changes.

Sold in multiples of 5 — minimum order 5

Supplier prices are confirmed before checkout. If one has changed since this page was updated, we show you the new price before you pay.

Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
IC3/8
GradeKC5010
MaterialCarbide
CoatingAlTiN

Description

The Kennametal 1865953 is a RCMK090700 carbide indexable insert, grade KC5010, AlTiN coated. Suited for steel, stainless steel, cast iron, non-ferrous metal, superalloys & titanium, hard material.

Specifications

ApplicationsProfiling; Turning
ChipbreakerNone
Coating finishAlTiN
Coating processPVD
Corner radius0.1875
Hole diameter0.0000
Included angle360
Inscribed circle in3/8
Insert handNeutral
Insert height0.5210
Insert holding methodClamp; Pin
Insert length in3/8
Insert materialCarbide
Insert size code35
Insert styleRCMK
Iso codeRCMK090700
Manufacturer gradeKC5010
Material gradeP10; P20; M10; M20; K05; K10; K15; K20; N10; N20; S10; S20; H10
Maximum depth of cut0.1875
Msc manufacturer numberRCMK35
Number of cutting edges4
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Non-Ferrous Metal; Superalloys & Titanium; Hard Material
RakePositive
Rake angle7
Relief angle5
ShapeRound
Side length0.3750
StandardsRCMK35; RCMK090700
Thickness0.5210
Width in3/8
