Kennametal
RCGT250900SHF Solid Carbide Insert, Grade KCPK30, TiN - Kennametal 2270901
MFR# 2270901ISO/ANSI# RCGT250900SHFCat# RCGT250900SHFSeries RCGT
$53.37List $64.01
Save 16%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
⚡ Need it urgently? Confirm stock & ship time →
Sold in multiples of 5 — minimum order 5
Request a quote- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1
ShapeRound
GradeKCPK30
MaterialSolid Carbide
CoatingTiN
Description
The Kennametal 2270901 is a RCGT250900SHF solid carbide indexable insert, grade KCPK30, TiN coated. Suited for steel, stainless steel, cast iron, superalloys & titanium.
Specifications
Ansi codeRCGT86SHF
Chip breakerHF
Coating finishTiN
Coating processCVD
Cutter series compatibilityKSRM
Cutting edge styleChamfered; Honed
Hole diameter0.2559
Included angle degree360
Inscribed circle in1
Inscribed circle range1.0000+
Insert handNeutral
Insert holding methodScrew
Insert materialSolid Carbide
Insert shapeRound
Insert size8
Insert size code86
Insert styleRCGT
Iso codeRCGT250900SHF
Length in1
Length range1.0000+
Manufacturers catalog numberRCGT250900SHF
Manufacturer gradeKCPK30
Material applicationSteel; Stainless Steel; Cast Iron; Superalloys & Titanium
Material gradeC1; C5; C6
Multi use toolYes
Number of cutting edges4
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Superalloys & Titanium
RakePositive
Rake angle25
Relief angle7.00
Single or double sided insertSingle
StandardsANSI; ISO
Thickness in3/8
Thickness range0.3500 to 0.5000
Width in1
