Kennametal
RCMT2006M0 PCBN Insert, Grade KB1345 - Kennametal 3383295
MFR# 3383295ISO/ANSI# CPGW060204
$138.84List $166.49
Save 16%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/4
ShapeC - Diamond (Rhombic) 80-Deg
GradeKB1345
MaterialPCBN
Description
The Kennametal 3383295 is a RCMT2006M0 pcbn indexable insert, grade KB1345.
Specifications
Ansi insert codeCPGW21.51
Ansi size code21.51
Chip breakerW
Clearance codeP
Corner radius in1/64
Grade characteristicsCast Iron (K) - Moderate Wear-Resistance and Toughness to High Toughness
Included angle80
Industry standard numberRCGV35E
Inscribed circle in1/4
Insert holding methodScrew
Insert materialPCBN
Insert shapeC - Diamond (Rhombic) 80-Deg
Insert size code21.51
Insert styleCPGW
Insert thickness in3/32
Iso codeRCMT2006M0
Iso insert codeCPGW060204
Iso size code060204
Manufacturers catalog number3383295
Manufacturer gradeKB1345
Relief angle11
Side clearancePositive
Tolerance codeG
