Kennametal
DNMG190612RM Carbide Insert, Grade KC5010, TiAlN - Kennametal 3652912
MFR# 3652912ISO/ANSI# DNMG190612Series KENLOC
$53.87List $65.75
Save 18%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC5/8
ShapeD - Diamond (Rhombic) 55-Deg
GradeKC5010
MaterialCarbide
CoatingTiAlN
Description
The Kennametal 3652912 is a DNMG190612RM carbide indexable insert, grade KC5010, TiAlN coated. Suited for steel, stainless steel, superalloys & titanium.
Specifications
Ansi insert codeDNMG543
Ansi size code543
Chip breakerRM
Chip breaker operationRoughing; Medium Machining
Clearance codeN
Coating finishTiAlN
Coating processPVD
Corner radius in3/64
Cutting edge styleChamfered; Honed
Full radiusNo
Grade characteristicsSteel (P) - High Wear-Resistance to Moderate Wear-Resistance and Toughness; Stainless Steel (M) - High Wear-Resistance to Moderate Wear-Resistance and Toughness; Cast Iron (K) - High Wear-Resistance to Moderate Wear-Resistance and Toughness; Aluminum & No
Hole diameter0.2500
Included angle55
Industry standard numberDNMG543RM
Inscribed circle in5/8
Insert handNeutral
Insert holding methodClamp; Pin
Insert length1.5260
Insert materialCarbide
Insert shapeD - Diamond (Rhombic) 55-Deg
Insert size code543
Insert styleDNMG
Insert thickness in1/4
Iso codeDNMG190612RM
Iso insert codeDNMG190612
Iso size code190612
Length range0.7000 - 10.0000
Manufacturers catalog number3652912
Manufacturer gradeKC5010
Material gradeC3; C4
Maximum depth of cut0.5082
Multi use applicationTurning; Facing; Boring; Back Turning; Back Boring
Multi use toolYes
Number of cutting edges4
Primary workpiece materialSteel; Stainless Steel; Superalloys & Titanium
RakeNegative
Rake angle0
Relief angle0
Side clearanceNegative
StandardsANSI; ISO
Tolerance codeM
Width in5/8
Wiper edgeNo
