DNGA150408S01025MT PCBN Insert, Grade KB5630, AlTiN - Kennametal 3747225

Kennametal

DNGA150408S01025MT PCBN Insert, Grade KB5630, AlTiN - Kennametal 3747225

MFR# 3747225ISO/ANSI# DNGA150408Series KENLOC

$139.06List $166.75 Save 16%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
IC1/2
ShapeD - Diamond (Rhombic) 55-Deg
GradeKB5630
MaterialPCBN
CoatingAlTiN

Description

The Kennametal 3747225 is a DNGA150408S01025MT pcbn indexable insert, grade KB5630, AlTiN coated. Suited for hard material.

Specifications

Ansi insert codeDNGA432
Ansi size code432
Chip breakerFlat Top
Chip breaker operationFlat Top
Clearance codeN
Coating finishAlTiN
Coating processPVD
Corner radius in1/32
Cutting edge styleChamfered; Honed
Full radiusNo
Grade characteristicsCast Iron (K) - High Wear-Resistance; Special, Super Alloys (S) - High Wear-Resistance
Hole diameter0.2031
Included angle55
Industry standard numberDNGA432S0425MT
Inscribed circle in1/2
Insert handNeutral
Insert holding methodClamp; Pin
Insert length1.2208
Insert materialPCBN
Insert shapeD - Diamond (Rhombic) 55-Deg
Insert size code432
Insert styleDNGA
Insert thickness in3/16
Iso codeDNGA150408S01025MT
Iso insert codeDNGA150408
Iso size code150408
Length range0.7000 - 10.0000
Manufacturers catalog number3747225
Manufacturer gradeKB5630
Material gradeH25; H35
Maximum depth of cut0.4065
Maximum depth of cut frac in13/32
Multi use applicationTurning; Facing; Boring; Back Turning; Back Boring
Multi use toolYes
Number of cutting edges2
Primary workpiece materialHard Material
RakeNegative
Rake angle0
Relief angle0
Side clearanceNegative
Single or multi tippedMulti Tipped
StandardsANSI; ISO
Tolerance codeG
Width in1/2
Wiper edgeNo
