Kennametal
Diamond 80 1/2" IC Carbide Insert, Grade KCM25, TiN - Kennametal 3758094
MFR# 3758094ISO/ANSI# CCMT432MFSeries Screw-On
$33.29List $40.64
Save 18%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/2
ShapeDiamond 80
GradeKCM25
MaterialCarbide
CoatingTiN
Description
The Kennametal 3758094 is a carbide indexable insert, grade KCM25, TiN coated. Suited for steel, stainless steel, superalloys & titanium.
Specifications
Chip breakerMF
Clearance codeC
Coating finishTiN
Coating processMTCVD
Corner radius in1/32
Cutting edge styleChamfered & Honed
Full radiusNo
Hole diameter0.2165
Included angle80degree
Industry standard numberCCMT432MF
Inscribed circle in1/2
Insert handNeutral
Insert holding methodScrew
Insert length0.5077
Insert materialCarbide
Insert shapeDiamond 80
Insert size code432
Insert styleCCMT
Insert thickness in3/16
Length range0.5000 - 0.6000
Manufacturers catalog number3758094
Manufacturer gradeKCM25
Material gradeC1; C2
Maximum depth of cut0.0492
Multi use applicationTurning; Facing; Boring
Multi use toolYes
Number of cutting edges2
Primary workpiece materialSteel; Stainless Steel; Superalloys & Titanium
RakePositive
Rake angle0
Relief angle7
StandardsANSI; ISO
Tolerance codeM
Width in1/2in
Wiper edgeNo
