Kennametal
Carbide Insert, Grade KCU25, TiAlN - Kennametal 3781260
MFR# 3781260Series A4
$45.56List $55.61
Save 18%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
GradeKCU25
MaterialCarbide
CoatingTiAlN
Description
The Kennametal 3781260 is a carbide indexable insert, grade KCU25, TiAlN coated.
Specifications
Chip breakerGUP
Coating finishTiAlN
Coating processBY; PVD
Corner radius0.0157
Cutting width0.2362
Full radiusNo
Insert handNeutral
Insert materialCarbide
Insert size0600
Insert styleA4G
Manufacturer gradeKCU25
Material gradeC2; C6
Maximum depth of cut0.1772
Maximum depth of cut range0.1500 to 0.2000
Measurement typeMetric
Multi use toolNo
Overall length1.1811
RakePositive
