R - Round 1/2" IC Carbide Insert, Grade KCS10, AlTiN - Kennametal 3787483

Kennametal

R - Round 1/2" IC Carbide Insert, Grade KCS10, AlTiN - Kennametal 3787483

MFR# 3787483ISO/ANSI# RPGV120700Series KENDEX

$39.73List $47.66 Save 16%
Usually ships in 1-3 business days

Ship times are estimates. We confirm availability on every order and email you right away if anything changes.

Sold in multiples of 5 — minimum order 5

Supplier prices are confirmed before checkout. If one has changed since this page was updated, we show you the new price before you pay.

Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
IC1/2
ShapeR - Round
GradeKCS10
MaterialCarbide
CoatingAlTiN

Description

The Kennametal 3787483 is a carbide indexable insert, grade KCS10, AlTiN coated. Suited for stainless steel, superalloys & titanium.

Specifications

Ansi insert codeRPGV45
Ansi size code45
Chip breakerMP
Chip breaker operationRoughing; Medium Machining
Clearance codeP
Coating finishAlTiN
Coating processPVD
Corner radius in1/4
Cutting edge styleHoned
Full radiusYes
Grade characteristicsSteel (P) - High Wear-Resistance to Moderate Wear-Resistance and Toughness; Stainless Steel (M) - High Wear-Resistance to Moderate Wear-Resistance and Toughness; Cast Iron (K) - High Wear-Resistance to Moderate Wear-Resistance and Toughness; Aluminum & No
Included angle360
Industry standard numberRPGV45MP
Inscribed circle in1/2
Insert handNeutral
Insert holding methodScrew
Insert length in1/2
Insert materialCarbide
Insert shapeR - Round
Insert size code45
Insert styleRPGV
Insert thickness in5/16
Iso insert codeRPGV120700
Iso size code120700
Length range0.5000 - 0.6000
Manufacturers catalog number3787483
Manufacturer gradeKCS10
Material gradeC3; C4
Maximum depth of cut0.1665
Multi use applicationTurning; Facing; Boring
Multi use toolYes
Number of cutting edges4
Primary workpiece materialStainless Steel; Superalloys & Titanium
RakePositive
Rake angle12
Relief angle11
Side clearancePositive
StandardsANSI; ISO
Tolerance codeG
Width in1/2
Wiper edgeNo
