Kennametal
3/4" Solid Carbide Stub Drill Bit, TiN, 140° point - Kennametal 4150416
MFR# 4150416Series B041A-CPG
$347.32List $445.45
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Drill size3/4
Flutes2
CoatingTiN
Description
The Kennametal 4150416 is a 3/4" Solid Carbide Stub drill bit with a TiN finish, 140° point. Series B041A-CPG.
Specifications
Coating finishTiN
Coolant throughNo
Cutting directionRight Hand
Drill bit diameter tolerance+0.0000 to -0.0008 in; -0.021 to 0.000 mm
Drill bit size in3/4
Drill bit size range0.6000+
Drill length typeStub
Drill point angle140
Drill point length0.1304
Flute by diameter ratio3xD
Flute length3.1102
Flute typeRegular Spiral
Maximum drilling depth2.1654
Number of flutes2
Overall length5.1575
Point typeStandard
Shank diameter0.7874
Shank length1.9685
Shank typeStraight
Specification designationDIN
Specification numberDIN 6537K
Spiral typeRegular
Tool materialSolid Carbide
Web configurationTapered
