Kennametal
SNGA120412S01225MT Carbide Insert, Grade KCP25B - Kennametal 6151564
MFR# 6151564ISO/ANSI# T110304
$23.33List $28.48
Save 18%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
ShapeT - Triangle
GradeKCP25B
MaterialCarbide
Description
The Kennametal 6151564 is a SNGA120412S01225MT carbide indexable insert, grade KCP25B.
Specifications
Ansi insert codeT221
Ansi size code221
Chip breakerP
Chip breaker operationRoughing; Medium Machining
Corner radius in1/64
Grade characteristicsSteel (P) - Moderate Wear-Resistance and Toughness; Aluminum & Non-Ferrous (N) - Moderate Wear-Resistance and Toughness to High Toughness
Included angle60
Industry standard numberDNMG432FP
Inscribed circle0.2500
Insert materialCarbide
Insert shapeT - Triangle
Insert size code221
Insert styleT
Insert thickness in1/8
Iso codeSNGA120412S01225MT
Iso insert codeT110304
Iso size code110304
Manufacturers catalog number6151564
Manufacturer gradeKCP25B
Side clearanceNegative
