Kennametal
DFPR070305MSO Carbide Insert, Grade KCMS35, AlTiN - Kennametal 7064676
MFR# 7064676ISO/ANSI# DFPR070305MSOSeries Drill Fix
$25.89List $31.60
Save 18%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
GradeKCMS35
MaterialCarbide
CoatingAlTiN
Description
The Kennametal 7064676 is a DFPR070305MSO carbide indexable insert, grade KCMS35, AlTiN coated.
Specifications
Ansi codeDFPR070305MSO
ChipbreakerMS
Coating finishAlTiN
Compatible drill styleDFPR
Corner radius0.0190
Included angle degree11
Inscribed circle0.3040
Insert materialCarbide
Insert size07
Insert size code07
Insert styleDFPR
Iso codeDFPR070305MSO
Length0.304
Manufacturer gradeKCMS35
Relief angle11
ShapeProprietary
Thickness (mm)2.8
Width0.304
