Kennametal
Diamond 5/8" IC Carbide Insert, Grade KCU10B, AlTiN - Kennametal 7093273
MFR# 7093273
$32.22List $39.33
Save 18%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC5/8
ShapeDiamond
GradeKCU10B
MaterialCarbide
CoatingAlTiN
Description
The Kennametal 7093273 is a carbide indexable insert, grade KCU10B, AlTiN coated.
Specifications
Chip breakerMP
Clearance codeN
Coating finishAlTiN
Corner radius in3/64
Included angle80
Inscribed circle in5/8
Insert handNeutral
Insert materialCarbide
Insert shapeDiamond
Insert size code543
Insert styleCNMG
Insert thickness in1/4
Manufacturer gradeKCU10B
Number of cutting edges8
Relief angle0.000
Tolerance codeM
Width in1/4
