Kyocera
RCGX120700P20015 Ceramic Insert, Grade A65, Al2O3 - Kyocera TCR61120
MFR# TCR61120ISO/ANSI# RCGX104T08015625AAA65Series ISOI
$30.76List $44.26
Save 30%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/2
ShapeRound
GradeA65
MaterialCeramic
CoatingAl2O3
Description
The Kyocera TCR61120 is a RCGX120700P20015 ceramic indexable insert, grade A65, Al2O3 coated. Suited for cast iron, hard material.
Specifications
Clearance codeC
Coating finishAl2O3
Coating processUncoated
Corner radius in1/4
Full radiusYes
Included angle360degree
Industry standard numberRCGX104T08015625AAA65
Inscribed circle in1/2
Insert handNeutral
Insert holding methodClamp
Insert length in1/2
Insert materialCeramic
Insert shapeRound
Insert size code104T0
Insert styleRCGX
Insert thickness in5/16
Iso codeRCGX120700P20015
Length range0.5000 - 0.6000
Manufacturers catalog numberTCR61120
Manufacturer gradeA65
Material gradeK01; K10; H01; H10
Maximum depth of cut0.2500
Multi use applicationExternal Turning; Facing; Roll Machining; Undercutting
Multi use toolYes
Number of cutting edges4
Primary workpiece materialCast Iron; Hard Material
RakePositive
Relief angle7
StandardsANSI; ISO
Tolerance codeG
Width in1/2in
Wiper edgeNo
