Kyocera
LNU6688T08015/625A Ceramic Insert, Grade A65, Al2O3 - Kyocera TCR80001
MFR# TCR80001ISO/ANSI# LNU6688T08015625AA65Series ISOI
$82.80List $119.14
Save 30%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC3/4
ShapeRectangle
GradeA65
MaterialCeramic
CoatingAl2O3
Description
The Kyocera TCR80001 is a LNU6688T08015/625A ceramic indexable insert, grade A65, Al2O3 coated. Suited for cast iron, hard material.
Specifications
Clearance codeN
Coating finishAl2O3
Coating processUncoated
Corner radius in1/8
Full radiusNo
Included angle90degree
Industry standard numberLNU6688T08015625AA65
Inscribed circle in3/4
Insert handNeutral
Insert holding methodClamp
Insert length in1-1/2
Insert materialCeramic
Insert shapeRectangle
Insert size code6688
Insert styleLNU
Insert thickness in1/2
Iso codeLNU6688T08015/625A
Length range0.7000 - 10.0000
Manufacturers catalog numberTCR80001
Manufacturer gradeA65
Material gradeK01; K10; H01; H10
Maximum depth of cut0.5000
Multi use applicationRoll Machining
Multi use toolNo
Number of cutting edges4
Primary workpiece materialCast Iron; Hard Material
RakeNegative
Relief angle0
StandardsANSI; ISO
Tolerance codeU
Width in3/4in
Wiper edgeNo
