Kyocera
RCGX106T08015625AA Ceramic Insert, Grade A66N, Al2O3 - Kyocera TCS89058
MFR# TCS89058ISO/ANSI# RCGX106T08015625AAA66NSeries ISOI
$57.32List $82.49
Save 30%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC3/4
ShapeRound
GradeA66N
MaterialCeramic
CoatingAl2O3
Description
The Kyocera TCS89058 is a RCGX106T08015625AA ceramic indexable insert, grade A66N, Al2O3 coated. Suited for hard material.
Specifications
Clearance codeC
Coating finishAl2O3
Coating processPVD
Corner radius in3/8
Full radiusYes
Included angle360degree
Industry standard numberRCGX106T08015625AAA66N
Inscribed circle in3/4
Insert handNeutral
Insert holding methodClamp
Insert length in3/4
Insert materialCeramic
Insert shapeRound
Insert size code106T0
Insert styleRCGX
Insert thickness0.3940
Iso codeRCGX106T08015625AA
Length range0.7000 - 10.0000
Manufacturers catalog numberTCS89058
Manufacturer gradeA66N
Material gradeH01; H10
Maximum depth of cut0.3750
Multi use applicationExternal Turning; Facing; Roll Machining; Undercutting
Multi use toolYes
Number of cutting edges4
Primary workpiece materialHard Material
RakePositive
Relief angle7
StandardsANSI; ISO
Tolerance codeG
Width in3/4in
Wiper edgeNo
