WPR 0500-CF LC610T Solid Carbide Insert, Grade LC610T, TiAlN - LMT 6122825
MFR# 6122825ISO/ANSI# WPR 0500-CF LC610TSeries WPR
$48.26List $61.90
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/2
ShapeBall Nose Rounded Tip
GradeLC610T
MaterialSolid Carbide
CoatingTiAlN
Description
The LMT 6122825 is a WPR 0500-CF LC610T solid carbide indexable insert, grade LC610T, TiAlN coated. Suited for cast iron.
Specifications
Ansi codeWPR 0500-CF LC610T
Chip breakerCF
Coating finishTiAlN
Coating processPVD
Cutting edge effective length0.5000
Inscribed circle in1/2
Inscribed circle range0.5000 to 0.5100
Insert handRight Hand
Insert holding methodScrew
Insert materialSolid Carbide
Insert shapeBall Nose Rounded Tip
Insert size05
Insert size code0500
Insert styleWPR
Iso codeWPR 0500-CF LC610T
Manufacturers catalog number6122825
Manufacturer gradeLC610T
Material applicationCast Iron; Steel
Material gradeC2; C3
Multi use toolNo
Number of cutting edges2
Primary workpiece materialCast Iron
Secondary workpiece materialSteel
Single or double sided insertSingle
StandardsISO
Thickness0.1000
Thickness range0.1000 to 0.1250
Width in1/2
