M.A. Ford.

1" 4-Flute Solid Carbide Corner Radius End Mill - M.A. Ford. 11110007

MFR# 11110007Series 111

$517.81List $664.11 Save 22%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter1

Flutes4

MaterialSolid Carbide

CoatingUncoated

Description

The M.A. Ford. 11110007 is a 1 4-flute Solid Carbide (Micrograin) corner radius end mill. Suited for steel, stainless steel, cast iron, non-ferrous metal, superalloys & titanium, hard material. 1-1/2 length of cut, 4 overall length. Series 111.

Specifications

CentercuttingYes

ChipbreakerNo

Coating finishUncoated

Coolant throughNo

Corner radius in1/8

Corner radius tolerance+0.0020 to -0.0020 in

Cutting directionRight Hand

End mill materialSolid Carbide

End typeCorner Radius

Extended reachNo

Flute directionRight Hand

Flute typeSpiral

For use withToolholder

Helix angle30

Helix styleMedium

Length of cut in1-1/2

Length typeRegular

Manufacturers catalog number11110007

Material applicationSteel; Stainless Steel; Cast Iron; Non-Ferrous Metal; Superalloys & Titanium; Hard Material

Material gradeMicrograin

Material removal typeRoughing & Finishing

Maximum helix angle30

Mill diameter in1

Mill diameter tolerance+0.0000 to -0.0030 in

Minimum helix angle30

Number of flutes4

Overall length in4

PitchNormal

Primary workpiece materialSteel; Stainless Steel; Cast Iron; Non-Ferrous Metal; Superalloys & Titanium; Hard Material

Reach length in1-1/2

Shank diameter in1

Shank typeStraight-Cylindrical

Single or double endSingle

Variable helixNo

Variable indexNo
