5/32" 2-Flute Solid Carbide Square End Mill - M.A. Ford. 13615621

M.A. Ford.

5/32" 2-Flute Solid Carbide Square End Mill - M.A. Ford. 13615621

MFR# 13615621Series 136

$37.23List $47.76 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter5/32
Flutes2
MaterialSolid Carbide

Description

The M.A. Ford. 13615621 is a 5/32 2-flute Solid Carbide square end mill. Suited for non-ferrous metal. 9/16 length of cut, 2 overall length. Series 136.

Specifications

CentercuttingYes
ChipbreakerNo
Cutting directionRight Hand
End mill materialSolid Carbide
Extended reachNo
Flute directionRight Hand
Flute typeHelical
Helix angle45
Length of cut in9/16
Length of cut range0.5000 - 0.6000
Mill diameter in5/32
Mill diameter tolerance+0.000 to -0.002 in
Number of flutes2
Overall length in2
Primary workpiece materialNon-Ferrous Metal
Shank diameter in5/32
Shank diameter toleranceh6
Shank typeStraight-Cylindrical
Variable helixNo
Variable indexNo
Can't find your exact tool?Send us a part number — we'll cross-reference it. Dull tools?Regrinding extends tool life and saves cost.

Alternate & equivalent tools

Matched on diameter, flute count, and material. Need a specific brand or coating? Cross-reference this tool.

OSG5/32" 2-Flute Solid Carbide Square End Mill, TiAlN - OSG HP421-1562 $25.52 Harvey Tool5/32" 2-Flute Solid Carbide Square End Mill - Harvey Tool 72156-C4 $42.31 Harvey Tool5/32" 2-Flute Solid Carbide Square End Mill - Harvey Tool 72156 $21.85 Harvey Tool5/32" 2-Flute Solid Carbide Square End Mill, TiB2 - Harvey Tool 24210-C8 $38.92
