3/16" 2-Flute Solid Carbide Square End Mill - M.A. Ford. 13618752

M.A. Ford.

3/16" 2-Flute Solid Carbide Square End Mill - M.A. Ford. 13618752

MFR# 13618752Series 136

$65.94List $84.56 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter3/16
Flutes2
MaterialSolid Carbide
CoatingBright/Uncoated

Description

The M.A. Ford. 13618752 is a 3/16 2-flute Solid Carbide (Micrograin) square end mill. Suited for non-ferrous metal. 1 length of cut, 2-1/2 overall length. Series 136.

Specifications

CentercuttingYes
ChipbreakerNo
Coating finishBright/Uncoated
Cutting directionRight Hand
End mill materialSolid Carbide
Extended reachNo
Flute directionRight Hand
Flute typeHelical
Helix angle45
Length of cut in1
Length of cut range1.0000 - 1.2500
Material gradeMicrograin
Mill diameter in3/16
Mill diameter tolerance+0.000 to -0.002 in
Number of flutes2
Overall length in2-1/2
Primary workpiece materialNon-Ferrous Metal
Shank diameter in3/16
Shank diameter toleranceh6
Shank typeStraight-Cylindrical
Variable helixNo
Variable indexNo
