1/8" 4-Flute Solid Carbide Ball End Mill, AlTiN - M.A. Ford. 14012500A

M.A. Ford.

1/8" 4-Flute Solid Carbide Ball End Mill, AlTiN - M.A. Ford. 14012500A

MFR# 14012500ASeries 140

$27.78List $35.62 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter1/8
Flutes4
MaterialSolid Carbide
CoatingAlTiN

Description

The M.A. Ford. 14012500A is a 1/8 4-flute Solid Carbide ball end mill with a AlTiN finish for longer tool life. 3/8 length of cut, 1-1/2 overall length. Series 140.

Specifications

ChipbreakerNo
Coating finishAlTiN
Coolant throughNo
Cutting directionRight Hand
End mill materialSolid Carbide
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
Helix angle30
Length of cut in3/8
Length typeStandard
Mill diameter in1/8
Mill diameter tolerance+0.000/-0.002 in
Nose radius0.0625
Number of flutes4
Overall length in1-1/2
Shank diameter in1/8
Single or double endSingle
Variable helixNo
Variable indexNo
