M.A. Ford.
1/4" 4-Flute Solid Carbide Ball End Mill, AlTiN - M.A. Ford. 14025000A
MFR# 14025000ASeries 140
$47.40List $60.80
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Diameter1/4
Flutes4
MaterialSolid Carbide
CoatingAlTiN
Description
The M.A. Ford. 14025000A is a 1/4 4-flute Solid Carbide ball end mill with a AlTiN finish for longer tool life. 3/4 length of cut, 2-1/2 overall length. Series 140.
Specifications
ChipbreakerNo
Coating finishAlTiN
Coolant throughNo
Cutting directionRight Hand
End mill materialSolid Carbide
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
Helix angle30
Length of cut in3/4
Length typeStandard
Mill diameter in1/4
Mill diameter tolerance+0.000/-0.002 in
Nose radius0.1250
Number of flutes4
Overall length in2-1/2
Shank diameter in1/4
Single or double endSingle
Variable helixNo
Variable indexNo
