M.A. Ford.

3/8" 4-Flute Solid Carbide Ball End Mill, AlTiN - M.A. Ford. 14037500A

MFR# 14037500ASeries 140

$74.85List $96.00 Save 22%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter3/8

Flutes4

MaterialSolid Carbide

CoatingAlTiN

Description

The M.A. Ford. 14037500A is a 3/8 4-flute Solid Carbide ball end mill with a AlTiN finish for longer tool life. 1 length of cut, 2-1/2 overall length. Series 140.

Specifications

ChipbreakerNo

Coating finishAlTiN

Coolant throughNo

Cutting directionRight Hand

End mill materialSolid Carbide

Extended reachNo

Flute directionRight Hand

Flute typeSpiral

Helix angle30

Length of cut in1

Length typeStandard

Mill diameter in3/8

Mill diameter tolerance+0.000/-0.003 in

Nose radius0.1875

Number of flutes4

Overall length in2-1/2

Shank diameter in3/8

Single or double endSingle

Variable helixNo

Variable indexNo
