M.A. Ford.

1/2" 5-Flute Solid Carbide Corner Radius End Mill - M.A. Ford. XV5CB50044AQW

MFR# XV5CB50044AQWSeries XV5CB

$216.24List $277.34 Save 22%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter1/2

Flutes5

MaterialSolid Carbide

Description

The M.A. Ford. XV5CB50044AQW is a 1/2 5-flute Solid Carbide corner radius end mill. Suited for steel, stainless steel, superalloys & titanium. 2-1/8 length of cut, 4 overall length. Series XV5CB.

Specifications

CentercuttingNo

ChipbreakerYes

Coolant throughNo

Corner radius0.0300

Cutting directionRight Hand

End mill materialSolid Carbide

End typeCorner Radius

Extended reachNo

Flute directionRight Hand

Flute typeHelical

For use withToolholder

Helix styleHigh

Length of cut in2-1/8

Length typeLong

Manufacturers catalog numberXV5CB50044AQW

Material applicationAlloy Steel; Stainless Steel; Titanium Alloy

Material removal typeFinishing

Mill diameter in1/2

Mill diameter tolerance+0.0000 to -0.0025 in

Number of flutes5

Overall length in4

PitchClose

Primary workpiece materialSteel; Stainless Steel; Superalloys & Titanium

Reach length in2-1/8

Shank diameter in1/2

Shank diameter tolerance+0.0000 to -0.0004 in

Shank typeWeldon Flat

Single or double endSingle

Variable helixNo

Variable indexYes
