Micro 100
Diamond 3/8" IC Carbide Insert - Micro 100 50-1105
MFR# 50-1105Cat# CCMT 31.51Series CCMT
$20.42List $23.43
Save 12%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
⚡ Need it urgently? Confirm stock & ship time →
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC3/8
ShapeDiamond
MaterialCarbide
Description
The Micro 100 50-1105 is a carbide indexable insert.
Specifications
Chip breakerFlat Top
Clearance codeC
Corner radius in1/64
Cutting edge styleHoned
Full radiusNo
Included angle80
Inscribed circle in3/8
Insert handNeutral
Insert holding methodScrew
Insert length0.3820
Insert materialCarbide
Insert shapeDiamond
Insert size code31.51
Insert styleCCMT
Insert thickness in3/32
Manufacturers catalog numberCCMT 31.51
Maximum depth of cut0.1272
Multi use applicationTurning; Facing; Chamfering; Boring
Multi use toolYes
Number of cutting edges2
RakePositive
Relief angle7
StandardsANSI; ISO
Tolerance codeM
Width in3/8
Wiper edgeNo
