Micro 100
APKT1003PDR Solid Carbide Insert - Micro 100 50-2100
MFR# 50-2100ISO/ANSI# APKT1003PDRCat# APKT1003PDRSeries APKT
$18.24List $21.29
Save 14%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
ShapeParallelogram
MaterialSolid Carbide
Description
The Micro 100 50-2100 is a APKT1003PDR solid carbide indexable insert. Suited for universal.
Specifications
Ansi codeAPKT1003PDR
Chip breakerCommon
Coating processUncoated
Corner radius in1/64
Cutter series compatibility30-xxxx; 31-xxxx
Cutting edge styleSingle Sided
Included angle degree85
Insert handRight Hand
Insert holding methodScrew
Insert materialSolid Carbide
Insert shapeParallelogram
Insert size10
Insert size code1003
Insert styleAPKT
Iso codeAPKT1003PDR
Length0.3940
Length range0.3200 to 0.4000
Manufacturers catalog numberAPKT1003PDR
Maximum depth of cut0.2955
Multi use toolYes
Number of cutting edges2
Primary workpiece materialUniversal
RakePositive
Relief angle11.00
Single or double sided insertSingle
StandardsISO
Thickness in1/8
Thickness range0.1250 to 0.1500
