Mitutoyo
0.0250" Dial Indicator, 0.000100" grad - Mitutoyo 1803AB-10
MFR# 1803AB-10
$182.72List $220.00
Save 16%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The Mitutoyo 1803AB-10 is a 0.0250" dial indicator. 0.000100" graduation. Meets ANSI/AGD.
Specifications
Accuracy0.000100
Agdgpno0
Back typeFlat
Bearing typeJeweled
Dial colorWhite
Dial diameter (mm)40.00
Dial graduation0.000100
Dial reading0-5-0
FeaturesShockproof
IncludesGreen Limit Markers; Plastic Case
Maximum measurement0.0250
Measuring force n1.40
Minimum measurement0.0000
Overall length (mm)75.90
Range per revolution0.0100
Revolution counterYes
StandardsANSI/AGD
Stem diameter in3/8
Stem length (mm)13.30
Thread size#4-48
