Mitutoyo
Dial Indicator - Mitutoyo 2046A-11
MFR# 2046A-11
$119.60List $144.00
Save 16%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The Mitutoyo 2046A-11 is a dial indicator. Meets ANSI/AGD.
Specifications
Accuracy (mm)0.0100
Agdgpno2
Back typeLug
Bearing typeJeweled
Dial colorYellow
Dial diameter (mm)57.00
Dial graduation (mm)0.0100
Dial reading0-100
FeaturesCrystal is Glare-Free; Scratch-Resistant
IncludesLimit Markers; Plastic Case
Maximum measurement (mm)10.00
Measuring force n1.40
Overall length (mm)109.90
Range per revolution (mm)1.00
Revolution counterYes
StandardsANSI/AGD
Stem diameter0.3750
Stem length (mm)13.60
Thread size#4-48
Unit of measureMetric
