Mitutoyo
0.0500" Feeler Gage, 0.000050" grad - Mitutoyo 7326A
MFR# 7326A
$289.86List $349.00
Save 16%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The Mitutoyo 7326A is a feeler gage. 0.000050" graduation.
Specifications
Accuracy0.0002 in; 0.0002
Accuracy micro m0.0002 in
Anvil face diameter12mm
Anvil face materialCeramic
Anvil tip shapeFlat
Dial diameter in2
FeaturesCorrosion-Resistant; Durable; Glare-Free Crystal; Mechanical Technology; Scratch-Resistant Coating
Flat contact diameter4mm
Graduation0.000050
Maximum measurement in0.0500
Measuring force n1.40
Throat depth1.1811
