Triangle 0.0980" IC Carbide Insert, Grade ZM3, TiN - NTK 7907258

NTK

Triangle 0.0980" IC Carbide Insert, Grade ZM3, TiN - NTK 7907258

MFR# 7907258ISO/ANSI# TBP60FR00Series TBP

$47.56List $61.00 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
ShapeTriangle
GradeZM3
MaterialCarbide
CoatingTiN

Description

The NTK 7907258 is a carbide indexable insert, grade ZM3, TiN coated. Suited for steel, stainless steel, non-ferrous metal.

Specifications

Chip breakerCommon
Clearance codeB
Coating finishTiN
Coating processPVD
Corner radius0.0000
Cutting edge styleHoned
Full radiusNo
Included angle60
Industry standard numberTBP60FR00
Inscribed circle0.0980
Insert handRight Hand
Insert holding methodScrew
Insert length0.7870
Insert materialCarbide
Insert shapeTriangle
Insert size code60
Insert styleTBP
Insert thickness0.3150
Length range0.7000 - 10.0000
Manufacturers catalog number7907258
Manufacturer gradeZM3
Material gradeMicrograin
Maximum depth of cut0.2623
Multi use applicationTurning; Facing; Boring
Multi use toolYes
Number of cutting edges3
Primary workpiece materialSteel; Stainless Steel; Non-Ferrous Metal
Relief angle12
StandardsANSI; ISO
Tolerance codeP
Width0.098
Wiper edgeNo
