OSG
#10-24 UNC High-Speed Steel Standard Tap, Oxide - OSG 1024901
MFR# 1024901Series 102
$7.31List $9.37
Save 21%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes4
Thread size#10-24
CoatingOxide
Description
The OSG 1024901 is a #10-24 UNC High-Speed Steel Standard tap with a Oxide finish. 4 flutes.
Specifications
ChamferPlug
Class of fit2B; 3B
Coating finishOxide
Coolant throughNo
MaterialHigh-Speed Steel
Material applicationAluminum; Cast Aluminum; Cast Iron; High-Carbon Steel; Low-Carbon Steel; Medium-Carbon Steel
Neck length1.4724
Number of flutes4
Overall length in2-3/8
OversizeNo
Shank diameter0.194
Square length0.25
Square size0.152
Tap typeStandard
Threads per inch24
Thread directionRight Hand
Thread length in7/8
Thread limitH3
Thread size in#10-24
Thread standardUNC
