OSG
#3-56 UNF Cobalt Tap - OSG 1400104400
MFR# 1400104400Series 14001
$19.74List $25.32
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Thread size#3-56
Description
The OSG 1400104400 is a #3-56 UNF Cobalt tap.
Specifications
ApplicationBlind Hole Threading
ChamferModified Bottoming
Chamfered threads2-2.5P
Class of fit2B
Coolant throughNo
MaterialCobalt
Material applicationAlloy Steel; Aluminum; Carbon Steel; Die Steel; Hardened Steel; Stainless Steel
Material application codeP; N
Overall length in1-13/16
Shank diameter0.1410
Square length0.1875
Square size0.1100
Tapping depth0.5350
Threads per inch56
Thread directionRight Hand
Thread length0.4960
Thread limitH3
Thread size in#3-56
Thread standardUNF
Trade nameHY-PRO NRT
