OSG
#6-32 UNC Vanadium High-Speed Steel Tap, TiCN - OSG 1722208
MFR# 1722208Series 303
$29.17List $37.40
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes3
Thread size#6-32
CoatingTiCN
Description
The OSG 1722208 is a #6-32 UNC Vanadium High-Speed Steel tap with a TiCN finish. 3 flutes.
Specifications
ChamferModified Bottoming
Coating finishTiCN
Coolant throughNo
Flute directionRight Hand
Flute styleSpiral
Helix angle45
MaterialVanadium High-Speed Steel
Material applicationStainless Steel; High-Carbon Steel; Low-Carbon Steel; Medium-Carbon Steel
Neck length (mm)49
Number of flutes3
Overall length in2
OversizeYes
Shank diameter0.1410
Square length0.1875
Square size0.11
Threads per inch32
Thread directionRight Hand
Thread length0.248
Thread limitH5
Thread size in#6-32
Thread standardUNC
