OSG
#10-24 UNC Vanadium High-Speed Steel Tap, Steam Oxide - OSG 1749601
MFR# 1749601Series 303
$26.02List $33.38
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes3
Thread size#10-24
CoatingSteam Oxide
Description
The OSG 1749601 is a #10-24 UNC Vanadium High-Speed Steel tap with a Steam Oxide finish. 3 flutes.
Specifications
ChamferModified Bottoming
Class of fit2B
Coating finishSteam Oxide
Coolant throughNo
Flute directionRight Hand
Flute styleSpiral
Helix angle45
MaterialVanadium High-Speed Steel
Material applicationStainless Steel; High-Carbon Steel; Low-Carbon Steel; Medium-Carbon Steel
Neck length2.126
Number of flutes3
Overall length in2-3/8
Shank diameter0.48
Shank length0.1940
Square length0.25
Square size0.152
Threads per inch24
Thread directionRight Hand
Thread length0.327
Thread limitH7
Thread size in#10-24
Thread standardUNC
