1/4" 3-Flute Solid Carbide Square End Mill - OSG 20430100

OSG

1/4" 3-Flute Solid Carbide Square End Mill - OSG 20430100

MFR# 20430100Series 2043

$41.70List $53.48 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter1/4
Flutes3
MaterialSolid Carbide

Description

The OSG 20430100 is a 1/4 3-flute Solid Carbide square end mill. 1/4 length of cut, 2-1/2 overall length. Series 2043.

Specifications

CentercuttingNo
ChipbreakerNo
Cutting directionRight Hand
End mill materialSolid Carbide
Extended reachYes
Flute directionRight Hand
Flute typeSpiral
Helix angle45
Length of cut in1/4
Length of cut range0.2000 - 0.3000
Length typeRegular
Mill diameter in1/4
Mill diameter tolerance+0.000/-0.002 in
Neck diameter0.2460
Number of flutes3
Overall length in2-1/2
Reach length in1-1/8
Shank diameter in1/4
Variable helixNo
Variable indexNo
