1/2" 2-Flute Solid Carbide Corner Radius End Mill, DLC - OSG 28630400

OSG

1/2" 2-Flute Solid Carbide Corner Radius End Mill, DLC - OSG 28630400

MFR# 28630400Series 2863

$167.40List $214.69 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter1/2
Flutes2
MaterialSolid Carbide
CoatingDLC

Description

The OSG 28630400 is a 1/2 2-flute Solid Carbide corner radius end mill with a DLC finish for longer tool life. Suited for non-ferrous metal. 3/4 length of cut, 4 overall length. Series 2863.

Specifications

CentercuttingYes
ChipbreakerNo
Coating finishDLC
Coolant throughNo
Corner radius0.1200
Cutting directionRight Hand
End mill materialSolid Carbide
End typeCorner Radius
Extended reachYes
Flute directionRight Hand
Flute typeSpiral
For use withToolholders
Helix styleMedium
Length of cut in3/4
Length typeStub
Material applicationNon-Ferrous Metal
Material removal typeRoughing
Mill diameter in1/2
Mill diameter tolerance0.0000/-0.0012 in
Neck diameter0.4610
Number of flutes2
Overall length in4
PitchCoarse
Primary workpiece materialNon-Ferrous Metal
Reach length2.2050
Shank diameter in1/2
Shank diameter toleranceh6
Shank typeStraight-Cylindrical
Single or double endSingle
Variable helixNo
Variable indexNo
