OSG
3/8-16 UNC Vanadium High-Speed Steel Tap, Steam Oxide - OSG 2931501
MFR# 2931501Series 290
$36.43List $46.72
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes3
Thread size3/8-16
CoatingSteam Oxide
Description
The OSG 2931501 is a 3/8-16 UNC Vanadium High-Speed Steel tap with a Steam Oxide finish. 3 flutes.
Specifications
ChamferModified Bottoming
Coating finishSteam Oxide
Coolant throughNo
Flute directionRight Hand
Flute styleSpiral
Helix angle45
MaterialVanadium High-Speed Steel
Material applicationAlloy Steel; Carbon Steel; Cast Iron; Stainless Steel; Die Steel; Hardened Steel
Material grade3% Vanadium HSS
Neck length1.713
Number of flutes3
Overall length in2-15/16
OversizeNo
Shank diameter0.323
Square length0.4375
Square size0.286
Threads per inch16
Thread directionRight Hand
Thread length0.5
Thread limitH2
Thread size in3/8-16
Thread standardUNC
