OSG
5/16-24 UNF Solid Carbide Machine Tap, TiCN - OSG 3110908
MFR# 3110908Series 311
$243.87List $312.77
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes5
Thread size5/16-24
CoatingTiCN
Description
The OSG 3110908 is a 5/16-24 UNF Solid Carbide Machine tap with a TiCN finish. 5 flutes.
Specifications
ChamferModified Bottoming
Class of fit2B
Coating finishTiCN
Coolant throughNo
MaterialSolid Carbide
Material applicationHardened Steel
Neck length1.3780
Number of flutes5
Overall length3.5430
OversizeNo
Shank diameter0.318
Square length0.375
Square size0.238
Tap typeMachine
Threads per inch24
Thread directionRight Hand
Thread length in1-1/8
Thread size in5/16-24
Thread standardUNF
