OSG
3/4" 3-Flute Solid Carbide Square End Mill - OSG 403-7500
MFR# 403-7500Series 403
$139.58List $179.01
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Diameter3/4
Flutes3
MaterialSolid Carbide
Description
The OSG 403-7500 is a 3/4 3-flute Solid Carbide (Micrograin) square end mill. 1-1/2 length of cut, 4 overall length. Series 403.
Specifications
CentercuttingYes
ChipbreakerNo
Cutting directionRight Hand
End mill materialSolid Carbide
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
Helix angle30
Length of cut in1-1/2
Length of cut range1.5000 - 2.0000
Length typeRegular
Material gradeMicrograin
Mill diameter in3/4
Number of flutes3
Overall length in4
Shank diameter in3/4
Variable helixNo
Variable indexNo
Can't find your exact tool?Send us a part number — we'll cross-reference it.
Dull tools?Regrinding extends tool life and saves cost.
Alternate & equivalent tools
Matched on diameter, flute count, and material. Need a specific brand or coating? Cross-reference this tool.
SGS3/4" 3-Flute Solid Carbide Square End Mill, AlTiN - SGS 30846
$205.34
Kennametal3/4" 3-Flute Solid Carbide Square End Mill, TiAlN - Kennametal 6143977
$335.94
Seco0.75" 3-Flute Cobalt Roughing End Mill, TiCN - Seco 17013556
$90.45
Hertel3/4" 3-Flute Solid Carbide Square End Mill - Hertel 750015
$142.96
