1/8in" 4-Flute Solid Carbide Corner Radius End Mill, WXS - OSG 447100611

OSG

1/8in" 4-Flute Solid Carbide Corner Radius End Mill, WXS - OSG 447100611

MFR# 447100611Series 4471

$83.69List $107.33 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter1/8in
Flutes4
MaterialSolid Carbide
CoatingWXS

Description

The OSG 447100611 is a 1/8in 4-flute Solid Carbide (Micrograin) corner radius end mill with a WXS finish for longer tool life. Suited for steel, stainless steel, cast iron, superalloys & titanium, hard material. 1/8in length of cut, 2-1/4in overall length. Series 4471.

Specifications

CentercuttingYes
ChipbreakerNo
Coating finishWXS
Coolant throughNo
Corner radius0.0150
Cutting directionRight Hand
End mill materialSolid Carbide
End typeCorner Radius
Extended reachYes
Flute directionRight Hand
Flute typeSpiral
For use withToolholders
Helix styleHigh
Length of cut in1/8in
Length typeRegular
Material applicationSteel; Stainless Steel; Cast Iron; Superalloys & Titanium; Hard Material
Material gradeMicrograin
Material removal typeRoughing & Finishing
Mill diameter in1/8in
Mill diameter tolerance0.0000/-0.0008 in
Neck diameter0.1200in
Number of flutes4
Overall length in2-1/4in
PitchNormal
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Superalloys & Titanium; Hard Material
Reach length in1/2
Shank diameter in1/8in
Shank diameter toleranceh6
Shank typeStraight-Cylindrical
Single or double endSingle
Variable helixNo
Variable indexNo
