1/8in" 2-Flute Cobalt Ball End Mill - OSG 5230100
MFR# 5230100Series 523
$74.52List $93.92
Save 20%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
⚡ Need it urgently? Confirm stock & ship time →
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Diameter1/8in
Flutes2
MaterialCobalt
Description
The OSG 5230100 is a 1/8in 2-flute Cobalt (M42) ball end mill. Suited for steel. 3/8in length of cut, 3-1/16in overall length. Series 523.
Specifications
Additional informationHSS-Co End Mill High Performance Cobalt HSS End Mills For General Milling Applications
ChipbreakerNo
Coolant throughNo
Cutting directionRight Hand
End mill materialCobalt
Extended reachNo
Flute directionRight Hand
Flute typeHelical
Helix angle30
Helix styleMedium
Length of cut in3/8in
Length typeStandard
Manufacturers catalog number5230100
Material gradeM42
Material removal typeRoughing & Finishing
Mill diameter in1/8in
Mill diameter tolerance+0.0000/-0.0011 in
Neck length0.0000
Nose radius0.0625
Number of flutes2
Overall length in3-1/16in
Primary workpiece materialSteel
Reach length0.3750
Secondary workpiece materialStainless Steel; Cast Iron; Non-Ferrous Metal; Superalloys & Titanium; Hard Material
Shank diameter in3/8in
Shank typeWeldon Flat
Single or double endDouble
System of measurementFractional Inch
Variable helixNo
Variable indexNo
