1/8" 4-Flute Solid Carbide Square End Mill - OSG 84400423

OSG

1/8" 4-Flute Solid Carbide Square End Mill - OSG 84400423

MFR# 84400423

$69.42List $89.03 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter1/8
Flutes4
MaterialSolid Carbide

Description

The OSG 84400423 is a 1/8 4-flute Solid Carbide (Micrograin) square end mill. 5/16 length of cut, 2-1/2 overall length.

Specifications

CentercuttingYes
Cutting directionRight Hand
End mill materialSolid Carbide
Extended reachNo
Flute directionRight Hand
Helix angle43
Length of cut in5/16
Material gradeMicrograin
Mill diameter in1/8
Number of flutes4
Overall length in2-1/2
Shank diameter in1/4
Variable helixNo
Variable indexNo
Can't find your exact tool?Send us a part number — we'll cross-reference it. Dull tools?Regrinding extends tool life and saves cost.

Alternate & equivalent tools

Matched on diameter, flute count, and material. Need a specific brand or coating? Cross-reference this tool.

Harvey Tool1/8" 4-Flute Solid Carbide Corner Radius End Mill, AlTiN - Harvey Tool 980225-C3 $40.79 Harvey Tool1/8" 4-Flute Solid Carbide Corner Radius End Mill, AlTiN - Harvey Tool 32420-C3 $37.88 GWS1/8" 4-Flute Solid Carbide Corner Radius End Mill, FX1 - GWS 121557 $40.93 Cleveland1/8" 4-Flute Cobalt Square End Mill, TiN - Cleveland C32574 $32.94
