0.2362" 4-Flute Solid Carbide Corner Radius End Mill, Duarise - OSG 8556130

OSG

0.2362" 4-Flute Solid Carbide Corner Radius End Mill, Duarise - OSG 8556130

MFR# 8556130Series 8215

$57.44List $72.39 Save 20%
Usually ships in 1-3 business days

Ship times are estimates. We confirm availability on every order and email you right away if anything changes.

Supplier prices are confirmed before checkout. If one has changed since this page was updated, we show you the new price before you pay.

Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Flutes4
MaterialSolid Carbide
CoatingDuarise

Description

The OSG 8556130 is a 0.2362 4-flute Solid Carbide corner radius end mill with a Duarise finish for longer tool life. Suited for steel, stainless steel, cast iron, non-ferrous metal, superalloys & titanium, hard material. Series 8215.

Specifications

CentercuttingYes
ChipbreakerNo
Coating finishDuarise
Coolant throughNo
Corner radius (mm)0.30
Corner radius tolerance0.00 to -0.02 mm
Cutting directionRight Hand
End mill materialSolid Carbide
End typeCorner Radius
Extended reachNo
Flute directionRight Hand
Flute typeHelical
For use withToolholder
Helix styleVariable
Length of cut1.4173
Length typeRegular
Material applicationSteel; Stainless Steel; Cast Iron; Non-Ferrous Metal; Superalloys & Titanium; Hard Material
Material removal typeRoughing & Finishing
Mill diameter0.2362
Mill diameter tolerance0.00 to -0.02 mm
Number of flutes4
Overall length (mm)60.00
PitchNormal
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Non-Ferrous Metal; Superalloys & Titanium; Hard Material
Shank diameter (mm)6.00
Shank diameter toleranceh6
Shank typeStraight-Cylindrical
Single or double endSingle
Variable helixYes
Variable indexNo
