Parlec
DA300 Collet Chuck - Parlec EXT500
MFR# EXT500
$105.73List $130.41
Save 18%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
⚡ Need it urgently? Confirm stock & ship time →
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The Parlec EXT500 is a DA300 Collet Chuck.
Specifications
Collet nut diameter0.5620
Collet seriesDA300
Collet systemDouble Angle
Coolant typeThrough-Spindle
Head length1.3200
Hex diameter0.5620
Maximum collet capacity in1/4
Minimum collet capacity in1/32
Overall length6.8220
Projection1.3220
Shank diameter in1/2
Shank length5.50
Shank typeStraight
Through coolantYes
Tir0.000400
