ProMax
0.3125" 4-Flute Corner Radius End Mill, TiCN - ProMax 120-02012
MFR# 120-02012Series 120
$79.98List $100.79
Save 20%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
⚡ Need it urgently? Confirm stock & ship time →
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes4
CoatingTiCN
Description
The ProMax 120-02012 is a 0.3125 4-flute (Micrograin) corner radius end mill with a TiCN finish for longer tool life. 3/4 length of cut. Series 120.
Specifications
ChipbreakerNo
Coating finishTiCN
Corner radius0.0200
Cutting directionRight Hand
End typeCorner Radius
Extended reachNo
Flute directionRight Hand
Helix angle40
Length of cut in3/4
Length typeRegular
Material gradeMicrograin
Mill diameter0.3125
Mill diameter frac in5/16
Mill diameter tolerance+0.000000 to -0.003000 in
Number of flutes4
Shank diameter in5/16
Shank diameter tolerance-0.0001/-0.0004 in
Shank typeWeldon Flat
Single or double endSingle
