CNMG 12 04 04-PF 1515 Carbide Insert, Grade 1515, TiCN - Sandvik Coromant 5724723

Sandvik Coromant

CNMG 12 04 04-PF 1515 Carbide Insert, Grade 1515, TiCN - Sandvik Coromant 5724723

MFR# 5724723ISO/ANSI# CNMG120404Series T-Max P

$18.13List $23.25 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
IC1/2
ShapeC - Diamond (Rhombic) 80-Deg
Grade1515
MaterialCarbide
CoatingTiCN

Description

The Sandvik Coromant 5724723 is a CNMG 12 04 04-PF 1515 carbide indexable insert, grade 1515, TiCN coated. Suited for steel.

Specifications

Ansi insert codeCNMG431
Ansi size code431
Chip breakerPF
Chip breaker operationFinishing
Clearance codeN
Coating finishTiCN
Corner radius in1/64
Grade characteristicsSteel (P) - High Wear-Resistance
Hole diameter0.2032
Included angle80
Inscribed circle in1/2
Insert handNeutral
Insert holding methodClamp; Pin
Insert length0.5079
Insert materialCarbide
Insert shapeC - Diamond (Rhombic) 80-Deg
Insert size code431
Insert styleCNMG
Insert thickness in3/16
Iso codeCNMG 12 04 04-PF 1515
Iso insert codeCNMG120404
Iso size code120404
Length range0.5000 - 0.6000
Manufacturers catalog number5724723
Manufacturer grade1515
Maximum depth of cut0.4921
Number of cutting edges4
Primary workpiece materialSteel
Relief angle0
Secondary workpiece materialStainless Steel
Side clearanceNegative
Tolerance codeM
Wiper edgeNo
