RCKT 19 06 00-PH 4220 Solid Carbide Insert, Grade 4220, TiCN - Sandvik Coromant 5740518

Sandvik Coromant

RCKT 19 06 00-PH 4220 Solid Carbide Insert, Grade 4220, TiCN - Sandvik Coromant 5740518

MFR# 5740518ISO/ANSI# RCKT 19 06 00-PH 4220Cat# RCKT 19 06 00-PH 4220Series RCKT

$32.78List $42.05 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
IC3/4
ShapeRound
Grade4220
MaterialSolid Carbide
CoatingTiCN

Description

The Sandvik Coromant 5740518 is a RCKT 19 06 00-PH 4220 solid carbide indexable insert, grade 4220, TiCN coated. Suited for steel, cast iron, hard material.

Specifications

Ansi codeRCKT 19 06 00-PH 4220
Chip breakerPH
Coating finishTiCN
Coating processCVD
Convex radius0.3750
Corner radius in3/8
Cutter series compatibilityRA200
Cutting edge styleRounded
Hole diameter0.2559
Included angle degree360
Inscribed circle in3/4
Inscribed circle range0.7000 to 1.0000
Insert handNeutral
Insert holding methodScrew
Insert materialSolid Carbide
Insert shapeRound
Insert size19
Insert size code190600
Insert styleRCKT
Iso codeRCKT 19 06 00-PH 4220
Length in3/4
Length range0.7000 to 0.9000
Manufacturers catalog numberRCKT 19 06 00-PH 4220
Manufacturer grade4220
Material applicationSteel; Cast Iron; Hard Material
Material gradeP20; H25
Maximum depth of cut0.1098
Multi use toolYes
Number of cutting edges8
Primary workpiece materialSteel; Cast Iron; Hard Material
RakePositive
Relief angle7.00
Single or double sided insertSingle
StandardsANSI; ISO
Thickness in1/4
Thickness range0.2500 to 0.3500
Width in3/4
