Indexable Grooving - Sandvik Coromant 5742210
MFR# 5742210Cat# R151.20-10-30Series T-Max Q-Cut
$231.75List $241.92
Save 4%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
Supplier prices are confirmed before checkout. If one has changed since this page was updated, we show you the new price before you pay.
Request a quote- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The Sandvik Coromant 5742210 indexable grooving. Series T-Max Q-Cut.
Specifications
Back of bar to cutting edge4.0000
Coolant throughNo
Hand of holderRight Hand
Head height0.6250
Head length0.6250
Insert compatibilityN151.2-300-5E
Insert holding methodClamp
Insert seat size30.0
Internal or externalExternal
Manufacturers catalog numberR151.20-10-30
Maximum depth of cut0.6890
Maximum groove width (mm)4.15
Minimum groove width0.1181
Overall length (mm)101.60
Shank height in5/8
Shank length2.9800
Shank width diameter in5/8
Toolholder styleR/L151.20
