Sandvik Coromant
TPMT090204KMH13A Carbide Insert, Grade H13A - Sandvik Coromant 5755285
MFR# 5755285ISO/ANSI# TPMT090204Series CoroTurn 111
$10.44List $13.39
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC7/32
ShapeT - Triangle
GradeH13A
MaterialCarbide
Description
The Sandvik Coromant 5755285 is a TPMT090204KMH13A carbide indexable insert, grade H13A.
Specifications
Ansi insert codeTPMT1.81.51
Ansi size code1.81.51
Chip breakerKM
Chip breaker operationRoughing; Medium Machining
Clearance codeP
Corner radius in1/64
Grade characteristicsCast Iron (K) - High Wear-Resistance to Moderate Wear-Resistance and Toughness; Aluminum & Non-Ferrous (N) - High Wear-Resistance to Moderate Wear-Resistance and Toughness; Special, Super Alloys (S) - High Wear-Resistance to Moderate Wear-Resistance and T
Hole diameter0.0984
Included angle60
Inscribed circle in7/32
Insert handNeutral
Insert holding methodScrew
Insert length0.3898
Insert materialCarbide
Insert shapeT - Triangle
Insert size code1.81.51
Insert styleTPMT
Insert thickness in3/32
Iso codeTPMT090204KMH13A
Iso insert codeTPMT090204
Iso size code090204
Length range0.3000 - 0.4000
Manufacturers catalog number5755285
Manufacturer gradeH13A
Maximum depth of cut0.3740
Relief angle11
Side clearancePositive
Tolerance codeM
