Sandvik Coromant
DNMG 11 04 04-SF 1105 Carbide Insert, Grade 1105, TiAlN2 - Sandvik Coromant 6066615
MFR# 6066615ISO/ANSI# DNMG 11 04 04-SF 1105Series T-Max P
$20.51List $26.30
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC3/8
ShapeDiamond
Grade1105
MaterialCarbide
CoatingTiAlN2
Description
The Sandvik Coromant 6066615 is a DNMG 11 04 04-SF 1105 carbide indexable insert, grade 1105, TiAlN2 coated. Suited for stainless steel.
Specifications
Chip breakerSF
Clearance codeN
Coating finishTiAlN2
Coating processPVD
Corner radius in1/64
Hole diameter0.1500
Included angle55
Inscribed circle in3/8
Insert handNeutral
Insert holding methodClamp; Pin
Insert length0.4579
Insert materialCarbide
Insert shapeDiamond
Insert size code331
Insert styleDNMG
Insert thickness in3/16
Iso codeDNMG 11 04 04-SF 1105
Length range0.4000 - 0.5000
Manufacturers catalog number6066615
Manufacturer grade1105
Maximum depth of cut0.4421
Number of cutting edges4
Primary workpiece materialStainless Steel
Relief angle0
Secondary workpiece materialSuperalloy; Titanium
Tolerance codeM
Wiper edgeNo
