Sandvik Coromant
TCMT 09 02 08-KM 3210 Carbide Insert, Grade 3210, TiCN - Sandvik Coromant 6162328
MFR# 6162328ISO/ANSI# TCMT 09 02 08-KM 3210Series CoroTurn 107
$13.56List $17.39
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC7/32
ShapeTriangle
Grade3210
MaterialCarbide
CoatingTiCN
Description
The Sandvik Coromant 6162328 is a TCMT 09 02 08-KM 3210 carbide indexable insert, grade 3210, TiCN coated. Suited for cast iron.
Specifications
Chip breakerKM
Clearance codeC
Coating finishTiCN
Corner radius in1/32
Hole diameter0.0984
Included angle60
Inscribed circle in7/32
Insert handNeutral
Insert holding methodScrew
Insert length0.3689
Insert materialCarbide
Insert shapeTriangle
Insert size code1.81.52
Insert styleTCMT
Insert thickness in3/32
Iso codeTCMT 09 02 08-KM 3210
Length range0.3000 - 0.4000
Manufacturers catalog number6162328
Manufacturer grade3210
Maximum depth of cut0.3374
Number of cutting edges3
Primary workpiece materialCast Iron
Relief angle7
Tolerance codeM
Wiper edgeNo
